FMVSS 209 4.3 汽车安全带硬件要求 临安科达认证技术咨询服务有限公司   时间:2021-07-02   点击:1329 次
(1)安全带装置的附件硬件在经受S5.2(a)规定的条件后,除了地板下加强板和垫圈外围边缘或孔边缘允许亚铁腐蚀之外,安全带装置硬件的重要表面应该是无铁辅食的。



S4.3 Requirementsfor hardware.硬件要求

(a)      Corrosion resistance. (1) Attachment hardware of a seat beltassembly after being subjected to the conditionsspecified in S5.2(a) shall be free of ferrous corrosion on significant surfacesexcept for permissible ferrous corrosion at peripheral edges or edges of holeson underfloor reinforcing plates and washers. Alternatively, such hardware ator near the floor shall be protected against corrosion by at least anelectrodeposited coating of nickel, or copper and nickel with at least aservice condition number of SC2, and other attachment hardware shall beprotected by an electrodeposited coating of nickel, or copper and nickel with aservice condition number of SC1, in accordance with ASTM B456-79 (incorporatedby reference, see §571.5), but such hardware shall not be racked forelectroplating in locations subjected to maximum stress.

a)耐腐蚀性1)安全带装置的附件硬件在经受S5.2a)规定的条件后,除了地板加强板和垫圈外围边缘或孔边缘允许亚铁腐蚀之外,安全带装置硬件的重要表面应该是无铁辅食的。另外,根据铜和镍的电镀层,根据ASTM B456-79,在地板上或靠近地板的硬件应该至少有一层镍电镀层,或至少SC2运行条件树木的铜和镍保护免受辅食,而其他连接硬件也应通过镍电镀层来进行保护。SC1运行条件数目的铜和镍保护,但此类硬件不得在承受最大应力的位置进行电镀。

(2) Surfaces of buckles, retractors and metallic parts,other than attachment hardware, of a seat belt assembly after subjection to theconditions specified in S5.2(a) shall be free of ferrous or nonferrouscorrosion which may be transferred, either directly or by means of the webbing,to the occupant or his clothing when the assembly is worn. After test, bucklesshall conform to applicable requirements in paragraphs (d) to (g) of thissection.

2)在遵守S5.2a)规定的条件后,安全带装置的带扣,回卷器和金属零件(除附件硬件外)的表面应无铁或非铁腐蚀,这些腐蚀可直接转移或在着该装置时通过织带将其固定到乘员或其衣服上。试验后,带扣应符合本节(d)至(g)的适用要求。

(b) Temperatureresistance. Plastic or other nonmetallic hardware parts of a seat beltassembly when subjected to the conditions specified in S5.2(b) shall not warpor otherwise deteriorate to cause the assembly to operate improperly or fail tocomply with applicable requirements in this section and S4.4.

b)耐温性。安全带装置的塑料或其他非金属硬件零件在经受S5.2b)规定的条件时,不应该弯曲或损坏,从而导致装置无法正常运行或不符合本节和S4.4的适用要求。

(c) Attachmenthardware. (1) Eye bolts, shoulder bolts, or other bolt used to securethe pelvic restraint of seat belt assembly to a motor vehicle shall withstand aforce of 40,034 N when tested by the procedure specified in S5.2(c)(1), exceptthat attachment bolts of a seat belt assembly designed for installation inspecific models of motor vehicles in which the ends of two or more seat beltassemblies cannot be attached to the vehicle by a single bolt shall havebreaking strength of not less than 22,241 N.

c联接硬件。(1)按S5.2c)(1)规定的程序测试时,吊环螺栓,肩部螺栓或其他用于将安全带装置的骨盆保护装置固定在汽车上的螺栓应承受40,034 N的力,除了用来安装汽车指定型号的安全带装置的联接硬件(两个或多个安全带装置的末端不能通过单个螺栓固定到汽车上)以外,其断裂强度应不小于22241N

(2) Other attachment hardware designed to receive the endsof two seat belt assemblies shall withstand a tensile force of at least 26,689N without fracture of a section when tested by the procedure specified inS5.2(c)(2).

2)按S5.2c)(2)规定的程序进行测试时,旨在容纳两个安全带装置末端的其他附件硬件应承受至少26,689 N的拉力,而没有断裂剖面。

(3) A seat belt assembly having single attachment hooksof the quick-disconnect type for connecting webbing to an eye bolt shall beprovided with a retaining latch or keeper which shall not move more than 2 mmin either the vertical or horizontal direction when tested by the procedurespecified in S5.2(c)(3).

3当运用S5.2c)(3所说明的步骤进行测试时,安全带装置具有用于将织带连接到吊环螺栓的快速拆开型的单个联接吊钩,此联接吊钩应装有不能以垂直方向或水平方向移动超过2mm的固定销或定位螺钉。

(d) Bucklerelease. (1) The buckle of a Type 1 or Type 2 seat belt assembly shallrelease when a force of not more than 133 N is applied.

d)锁扣释放。(1)当施加至多133 N的力时,类型1或类型2安全带装置的带扣应释放。

(2) A buckle designed for pushbutton application ofbuckle release force shall have a minimum area of 452 mm2 witha minimum linear dimension of 10 mm for applying the release force, or a buckledesigned for lever application of buckle release force shall permit theinsertion of a cylinder 10 mm in diameter and 38 mm in length to at least themidpoint of the cylinder along the cylinder's entire length in the actuationportion of the buckle release. A buckle having other design for release shallhave adequate access for two or more fingers to actuate release.

2)设计用于安全带扣释放力的按钮应用的安全带扣应有运用释放力的452 mm2的最小面积和10mm最小线性尺寸,或用于安全带扣释放力的杠杆运用的安全带扣应沿着安全带扣释放的启动部分的汽缸全部长度,允许一个汽缸(直径为10mm和长度为38mm)插入到此汽缸的至少中点。用来释放的安全带扣应当允许两个或更多手指来促使释放。

(3) The buckle of a Type 1 or Type 2 seat belt assemblyshall not release under a compressive force of 1779 N applied as prescribed inparagraph S5.2(d)(3). The buckle shall be operable and shall meet theapplicable requirement of paragraph S4.4 after the compressive force has beenremoved.

31型或2型安全带装置的带扣不得在S5.2d)(3)款规定的施加的1779 N的压力下释放。在去除压缩力后,带扣应可操作并应符合S4.4的适用要求。

(e) Adjustmentforce. The force required to decrease the size of a seat belt assemblyshall not exceed 49 N when measured by the procedure specified in S5.2(e).

e)调整力。按照S5.2e)规定的程序进行测量时,减小安全带装置尺寸所需的力不得超过49N

(f) Tilt-lockadjustment. The buckle of a seat belt assembly having tilt-lockadjustment shall lock the webbing when tested by the procedure specified inS5.2(f) at an angle of not less than 30 degrees between the base of the buckleand the anchor webbing.

f)倾斜锁定调节。按S5.2f)规定的程序进行测试时,具有倾斜锁定调节功能的安全带装置的带扣应该以带扣和固定织带之间成至少30的角度来锁定织带

(g) Bucklelatch. The buckle latch of a seat belt assembly when tested by theprocedure specified in S5.2(g) shall not fail, nor gall or wear to an extentthat normal latching and unlatching is impaired, and a metal-to-metal buckleshall separate when in any position of partial engagement by a force of notmore than 22 N.

g安全带扣销。按照S5.2g)规定的程序进行测试时,安全带装置的带扣不应失效,也不得磨损或磨损到正常的封闭和非封闭状态被削弱的程度;当在部分接合的位置施加至多22N力时,一个金属对金属的安全带扣应相互分离。

(h) Nonlockingretractor. The webbing of a seat belt assembly shall extend from anonlocking retractor within 6 mm of maximum length when a tension is applied asprescribed in S5.2(h). A nonlocking retractor on upper torso restraint shall beattached to the nonadjustable end of the assembly, the reel of the retractorshall be easily visible to an occupant while wearing the assembly, and the maximumretraction force shall not exceed 5 N in any strap or webbing that contacts theshoulder when measured by the procedure specified in S5.2(h), unless theretractor is attached to the free end of webbing which is not subjected to anytension during restraint of an occupant by the assembly.

非锁定回卷器。当按S5.2h)的规定施加拉力时,安全带组件的安全带应从非锁定回卷器伸出,最大长度不得超过6 mm。上躯干约保护置上的非锁定回卷器应连接至组件的不可调节端,穿着者在佩戴组件时应易于看到回卷器的卷盘,并且任何皮带或织带中的最大牵拉力当按S5.2h)规定的程序进行测量时不得超过5 N ,该接触器与肩部接触,除非回卷器安装在安全带的自由端上,该自由端在组件保护乘员过程中不会受到任何拉力。

(i)       Automatic-locking retractor. The webbing of a seat beltassembly equipped with an automatic locking retractor, when tested by theprocedure specified in S5.2(i), shall not move more than 25 mm between lockingpositions of the retractor, and shall be retracted with a force under zeroacceleration of not less than 3 N when attached to pelvic restraint, and notless that 2 N nor more than 5 N in any strap or webbing that contacts theshoulders of an occupant when the retractor is attached to upper torso restraint.An automatic locking retractor attached to upper torso restraint shall notincrease the restraint on the occupant of the seat belt assembly during use ina vehicle traveling over rough roads as prescribed in S5.2(i).

自动锁定回卷器。当按照S5.2i)规定的程序进行测试时,配备有自动锁定回卷器的安全带组件的安全带在回卷器的锁紧位置之间移动的距离不得超过25 mm,并且应在有力的情况下将其收回当将其连接到骨盆保护装置上时,其加速度不得小于3 N,并且在将牵开器连接至上躯干保护装置时,与乘员肩部接触的任何皮带或织带中的加速度不得小于2 N,也不得大于5N。在S5.2i)规定的在崎岖不平的道路上行驶的车辆上使用时,安装在上躯干保护装置上的自动锁定回卷器不应增加对安全带组件乘员的约束。

(j) Emergency-lockingretractor.紧急锁定回卷器。

(1) For seatbelt assemblies manufactured before February 22, 2007. Except formanufacturers that, at the manufacturer's option, voluntarily choose to complywith S4.3(j)(2) during this period (with said option irrevocably selected priorto, or at the time of, certification of the seat belt assembly), anemergency-locking retractor of a Type 1 or Type 2 seat belt assembly, whentested in accordance with the procedures specified in paragraph S5.2(j)(1)—

适用于2007222日之前制造的安全带组件。除了在此期间自愿选择遵守S4.3j)(2)的制造商(在认证安全带组件之前或之时不可撤销地选择了该选项),根据第S5.2j)(1)段规定的程序进行测试的1型或2型安全带组件的紧急锁定回卷

(i) Shall lock before the webbing extends 25 mm when theretractor is subjected to an acceleration of 7 m/s2(0.7 g);

回卷器承受7 m / s20.7 g)的加速度时,在织带延伸25 mm之前应锁定;

(ii) Shall not lock, if the retractor is sensitive to webbingwithdrawal, before the webbing extends 51 mm when the retractor is subjected toan acceleration of 3 m/s2 (0.3 g) or less;

如果牵开器对安全带缩回敏感,则在锁紧器承受3 m / s20.3 g)或以下的加速度时,安全带在延伸51 mm之前不应锁定

(iii) Shall not lock, if the retractor is sensitive to vehicleacceleration, when the retractor is rotated in any direction to any angle of15° or less from its orientation in the vehicle;

如果回卷器对车辆的加速度敏感,则当回卷器以任何方向旋转至与其在车辆中的方向成15°或更小的角度时,均不应锁定;

(iv) Shall exert a retractive force of at least 3 N under zeroacceleration when attached only to the pelvic restraint;

仅附着在骨盆保护装置上时,在零加速度下应施加至少3 N的收缩力;

(v) Shall exert a retractive force of not less than 1 N and notmore than 5 N under zero acceleration when attached only to an upper torso restraint;

仅安装在上躯干保护装置上时,在零加速度下应施加不小于1 N且不大于5 N的收缩力;

(vi) Shall exert a retractive force not less than 1 N and not morethan 7 N under zero acceleration when attached to a strap or webbing thatrestrains both the upper torso and the pelvis.

当连接到保护上身和骨盆的带或织带时,在零加速度下应施加不小于1 N且不大于7 N的收缩力。

(2)     For seat belt assemblies manufactured on or after February 22, 2007 andfor manufacturers opting for early compliance. An emergency-lockingretractor of a Type 1 or Type 2 seat belt assembly, when tested in accordancewith the procedures specified in paragraph S5.2(j)(2)—

适用于2007222日或之后制造的安全带组件以及选择早期合规的制造商。根据第S5.2j)(2)段中规定的程序进行测试的1型或2型安全带组件的紧急锁定回卷

(i) Shall under zero acceleration loading—

须在零加速度负荷下

(A) Exert a retractive force of not less than 1 N and not morethan 7 N when attached to a strap or webbing that restrains both the uppertorso and the pelvis;

当安装在保护上身和骨盆的带或织带上时,应施加不小于1 N且不大于7 N的收缩力;

(B) Exert a retractive force not less than 3 N when attached onlyto the pelvic restraint; and

仅附着在骨盆保护装置上时应施加不小于3 N的收缩力;和

(C) Exert a retractive force of not less than 1 N and not morethan 5 N when attached only to an upper torso restraint.

仅安装在上躯干保护装置上时,应施加不小于1 N且不大于5 N的收缩力。

(D) For a retractor sensitive to vehicle acceleration, lock whentilted at any angle greater than 45 degrees from the angle at which it isinstalled in the vehicle or meet the requirements of S4.3(j)(2)(ii).

对于对车辆加速度敏感的回卷器,当其倾斜角度大于与安装在车辆中的角度大于45度或符合S4.3j)(2)(ii)的要求时,应锁定。

(E) For a retractor sensitive to vehicle acceleration, not lockwhen the retractor is rotated in any direction to any angle of 15 degrees orless from its orientation in the vehicle.

对于对车辆加速度敏感的回卷器,当回卷器沿任何方向旋转至与其在车辆中的方向成15度或更小的角度时,请不要锁定。

(ii) Shall lock before the webbing payout exceeds the maximumlimit of 25 mm when the retractor is subjected to an acceleration of 0.7 gunder the applicable test conditions of S5.2(j)(2)(iii)(A) or (B). Theretractor is determined to be locked when the webbing belt load tension is atleast 35 N.

在适用的S5.2j)(2)(iii)(A)或(B)的适用测试条件下,当回卷器承受0.7 g的加速度时,在织带支出超过最大限制25 mm之前应锁定当安全带的负载张力至少为35 N时,确定回卷器已锁定。

(iii) For a retractor sensitive to webbing withdrawal, shall notlock before the webbing payout extends to the minimum limit of 51 mm when theretractor is subjected to an acceleration no greater than 0.3 g under the testcondition of S5.2(j)(2)(iii)(C).

对于对织带退出敏感的回卷器,在S5.2j)(2)(iii)(C)的试验条件下,当回卷器承受的加速度不大于0.3 g时,在织带支出延伸至最小极限51 mm之前,不得锁定

(k) Performanceof retractor. A retractor used on a seat belt assembly aftersubjection to the tests specified in S5.2(k) shall comply with applicable requirementsin paragraphs (h) to (j) of this section and S4.4, except that the retractionforce shall be not less than 50 percent of its original retraction force.

回卷器的性能。在经过S5.2k)规定的测试后,用于安全带组件的回卷器应符合本节(h)至(j)和S4.4的适用要求,但卷收力应为不小于其原始回缩力的50%。
